Glide Centro Bariatric Mid Wheel Drive

Description

Active Pozi-Trak drive system. (APT)APT is a unique suspension system patented by Glide and was developed to enhance the performance of its latest Mid Wheel Drive wheelchair.
The APT system is a three-functional operation which increases traction on the Drive Wheels, aids with Kerb Climbing and acts as an anti-pitch device.
The suspension system also eliminates nose-dive when descending roadside kerbs.
The drive wheels are set positive, meaning when the wheelchair is on a level ground, a preload of up to 20kg (depending on spring set-up type) is on each drive wheel.
This unique system greatly improves traction for driving and braking.
It also performs extremely well in emergency downhill braking.
This system is a very low-maintenance system and has eliminated the need for complex moving parts that need constant servicing or adjustments.
Additionally, with the combination of varying spring setups, your wheelchair can be fine-tuned to suit your driving preference.
e.g. Biased for more traction or increased kerb climbing ability.
Video of the APT system in use at the bottom of this page.
SAFETY – Full compliance AS 3695 – 250kg.
Crash tested to AS 3696:19 to a Max user weight of 159kg.

Overview

Power Base type with easily removable seating module.
50 degree seat tilt standard.
Available in Adult and Paediatric versions.
Motors – High quality German motors - 4 Pole High torque.
Low seat height standard (46cm at 0 degrees).
Optional lower seat height 43cm.
70 – 90 amp/hr Batteries capabilities. (Amp/hr ratings varies between Battery brand)
Vehicle Tie Down points.
Low maintenance with easily accessible electronics.
Turn Circle between walls 1145mm (Average set up 46cm SD x 46cm SW).
80mm kerb climbing ability.
80mm Ground clearance.
Max Ramp Incline/Decline 10°
Glide’s all new seating system for Centro.
Compatibility to most Proprietary Seating systems on the market.
Plus all the standard options offered with our range.
